Expressionist

A small, header-only C++20 library that evaluates algebraic expressions embedded in nlohmann::json fields, replacing them in place with their computed values. Variables in an expression are simply other keys of the same JSON tree, so an object can describe a little spreadsheet of interdependent values.

// input                             // output (after evaluate)
{                                    {
  "a": 1,                              "a": 1,
  "b": 2,                              "b": 2,
  "c": "$a + b",                       "c": 3,
  "d": "plain string",                 "d": "plain string",
  "f": "$pi/3",                        "f": 1.0471975511965976,
  "g": "$sin(f) * b",                  "g": 1.7320508075688772,
  "h": true,                           "h": true,
  "i": false,                          "i": false,
  "j": "$h && i"                       "j": false
}                                    }

A string is treated as an expression only when it starts with the tag (default "$"); every other string is left untouched. The definition order of the variables does not matter — dependencies are resolved automatically, and circular dependencies or undefined variables are reported as errors with context.

Features

Header-only, zero runtime dependencies beyond nlohmann::json.
Hand-written tokenizer + Pratt parser — no third-party expression engine.
Integer/double/boolean results, preserving integer-ness ($a + b stays 3, $pi/3 becomes a double).
Arithmetic (+ - * / ^), comparisons (< <= > >= == !=) and logical operators (&& || !), with C-style precedence and short-circuiting.
A range operator that expands start:stop (integer) or start:stop:step (floating) into a JSON array, endpoint inclusive.
A library of mathematical functions and constants, extensible at runtime.
Two interchangeable resolution strategies (topological graph and memoized recursive) selectable per instance.
Recurses into nested objects and arrays with lexical scoping.
An opt-out key (default "expressionist", configurable) lets a subtree disable evaluation entirely, leaving large static fragments untouched.
An optional plain-C ABI (libexpressionist_c) and a ctypes-based Python package, for use from outside C++.
Clear ExpressionistException messages carrying the offending field and expression.
Consumable via CMake FetchContent.

Requirements

A C++20 compiler (tested with Clang / AppleClang).
CMake ≥ 3.20 with Ninja recommended.
nlohmann::json (fetched automatically when building this project).

Integration

CMake FetchContent (recommended)

include(FetchContent)
FetchContent_Declare(
  Expressionist
  GIT_REPOSITORY https://github.com/pbosetti/Expressionist.git
  GIT_TAG        main
)
FetchContent_MakeAvailable(Expressionist)

target_link_libraries(your_target PRIVATE Expressionist::Expressionist)

Linking the target transitively pulls in nlohmann::json and the include path, so #include <expressionist.hpp> just works.

Manual

Copy src/expressionist.hpp into your include path and make sure nlohmann/json.hpp is reachable.

Quick start

#include <expressionist.hpp>
#include <iostream>

int main() {
  std::string json_text = R"({
    "a": 1,
    "b": 2,
    "c": "$a + b",
    "f": "$pi / 3",
    "g": "$sin(f) * b"
  })";

  // Instantiate with a json object
  nlohmann::json data = nlohmann::json::parse(json_text);
  Expressionist::Expressionist ex1(data);
  ex1.evaluate();            // mutate the stored object in place
  std::cout << ex1.object().dump(2) << '\n';

  // or, equivalently, from a string (a bare string literal works too — it is
  // parsed as JSON rather than stored as a string value):
  Expressionist::Expressionist ex2(json_text);
  ex2.evaluate();            // mutate the stored object in place
  std::cout << ex2.object().dump(2) << '\n';
}

Use produce() when you want a new object and need to keep the original intact:

Expressionist::Expressionist ex(data);
nlohmann::json result = ex.produce();     // `data` is left unchanged

Evaluating a separate object

An engine can also evaluate an object supplied at call time instead of the one it stores. Construct it with just a strategy — the stored object stays empty — and pass the target to evaluate(json&) (mutates it in place) or produce(json) (returns an evaluated copy). Both reuse the engine's configured tag and symbol table, so one engine can be applied to many objects:

Expressionist::Expressionist ex(EvalMethod::RECURSIVE);
ex.addConstant("g0", 9.80665);

nlohmann::json a = nlohmann::json::parse(R"({"m": 2, "w": "$m * g0"})");
ex.evaluate(a);                           // mutates `a` in place

nlohmann::json b = ex.produce(            // returns a new object
    nlohmann::json::parse(R"({"x": 3, "y": "$x ^ 2"})"));

Choosing a strategy

using Expressionist::EvalMethod;

Expressionist::Expressionist ex(data, EvalMethod::RECURSIVE);
ex.setEvalMethod(EvalMethod::GRAPH);      // switch at any time

Both strategies produce identical results:

EvalMethod::GRAPH builds a dependency graph and evaluates it in topological order (Kahn's algorithm).
EvalMethod::RECURSIVE (default) evaluates lazily with memoization and a visiting-set for cycle detection.

Changing the tag

ex.setTag("@");     // now "@a + 1" is an expression and "$a + 1" is a literal

Extending the symbol table

ex.addConstant("g0", 9.80665);
ex.addUnaryFunction("double", [](double x) { return 2.0 * x; });
ex.addBinaryFunction("clampmax", [](double x, double m) { return std::min(x, m); });

Error handling

try {
  ex.evaluate();
} catch (const Expressionist::ExpressionistException &e) {
  std::cerr << e.what() << '\n';
  // e.g. In '/a' ("$missing + 1"): Undefined variable or constant: 'missing'
}

Command-line tool

An optional expressionist executable is provided (target expressionist_cli). It is not built by default; enable it with the EXPRESSIONIST_BUILD_TOOL option, which also pulls in cxxopts via FetchContent:

cmake -Bbuild -GNinja -DEXPRESSIONIST_BUILD_TOOL=ON
cmake --build build

The tool reads an input JSON, evaluates it, and prints the result to stdout. The input comes either from a positional argument or, if none is given, from stdin.

# JSON passed as an argument
expressionist '{"a":1,"b":2,"c":"$a + b","f":"$pi/3"}'

# JSON piped in on stdin
echo '{"a":1,"c":"$a + 10"}' | expressionist

# read from a file via the shell
expressionist < data.json

Output for the first command:

{
  "a": 1,
  "b": 2,
  "c": 3,
  "f": 1.0471975511965976
}

Every class option is exposed as a flag:

Option	Description	Default
`-m, --method arg`	Evaluation strategy: `graph` or `recursive`	`graph`
`-t, --tag arg`	Prefix that marks a string as an expression	`$`
`--disable-key arg`	Object key that, set to `false`, opts its subtree out of evaluation	`expressionist`
`--indent arg`	Spaces used when pretty-printing the output	`2`
`-c, --compact`	Emit compact, single-line JSON (overrides `--indent`)	off
`-h, --help`	Print usage and exit
`-V, --version`	Print version and exit

expressionist --method recursive --tag @ --compact '{"a":1,"b":"@a + 1"}'
# -> {"a":1,"b":2}

Exit codes: 0 on success, 1 on a JSON or evaluation error (e.g. a circular dependency or undefined variable, reported with context on stderr), and 2 on a usage error (bad option, unknown method, or no input).

C ABI and Python interface

For use from outside C++, a small extern "C" layer (expressionist_c.h / libexpressionist_c) exposes the engine as JSON-string-in, JSON-string-out: no C++ type ever crosses the boundary, so it is consumable from any language with a C FFI. A ctypes-based Python package wraps it.

Both are opt-in and off by default:

cmake -Bbuild -GNinja -DEXPRESSIONIST_BUILD_PYTHON=ON
cmake --build build
cmake --install build

EXPRESSIONIST_BUILD_PYTHON implies EXPRESSIONIST_BUILD_C_API and, on install, copies libexpressionist_c and the expressionist Python package into Python3_SITELIB — the site-packages of whichever python3 is first on PATH, so it lands in an active virtualenv automatically. import expressionist then just works, with no PYTHONPATH or LD_LIBRARY_PATH setup:

from expressionist import Expressionist, EvalMethod

ex = Expressionist(method=EvalMethod.RECURSIVE)
ex.set_tag("$")
result = ex.evaluate({"a": 1, "b": 2, "c": "$a + b"})
print(result["c"])  # 3

evaluate() accepts either a JSON-serializable Python object or a JSON string, and always returns a new object without mutating the input — there is no persistent "stored object" across the C boundary, unlike the C++ class. Errors (parse failures, undefined variables, circular dependencies) raise ExpressionistError with the same diagnostic text the C++ API produces. Expressionist is a context manager (with Expressionist() as ex:) for deterministic native cleanup, though __del__ covers it too.

To build just the shared library and header (e.g. for a non-Python FFI consumer) without the Python install step, use -DEXPRESSIONIST_BUILD_C_API=ON instead.

If you already have a shared object you'd rather point the Python wrapper at (a build-tree artifact, a custom install location), set EXPRESSIONIST_C_LIBRARY to its path — it takes precedence over the next-to-__init__.py lookup and the system library search.

Expression syntax

Category	Supported
Literals	integers, floats (`1.5`, `1.5e-3`), `true`, `false`
Arithmetic	`+ - * / ^` (power, right-associative), unary `-`
Comparison	`< <= > >= == !=`
Logical	`&& \|\| !` (short-circuiting, C-style truthiness)
Grouping	`( … )`
Sequences	`start:stop` (integer, step 1) and `start:stop:step` (floating), endpoint inclusive
Constants	`pi`, `e`, `tau`
Unary funcs	`sin cos tan asin acos atan sinh cosh tanh exp log ln log10 log2 sqrt cbrt abs floor ceil round trunc sign`
Binary funcs	`pow atan2 hypot min max mod`

Precedence (lowest → highest): range :, ||, &&, == !=, < <= > >=, + -, * /, unary - !, ^, primary. Power binds tighter than unary minus, so -2^2 evaluates to -4, and 2^3^2 is 2^(3^2) = 512. Because the range operator sits at the bottom, its parts are ordinary expressions (0 : 2*pi : pi/6).

Result types. + - * keep integer operands integral; / always yields a double; ^ stays integral for non-negative integer exponents; comparisons and logical operators yield booleans; mathematical functions yield doubles; the range operator yields a JSON array.

Sequences (ranges)

A range expands into a JSON array. The two-part form takes integer bounds and steps by 1; the three-part form is floating and steps by an explicit amount. Both are inclusive of the endpoint (within rounding), and a step pointing away from the endpoint produces an empty array.

{
  "ints":  "$1:5",          // -> [1, 2, 3, 4, 5]
  "halfs": "$0:1:0.25",     // -> [0.0, 0.25, 0.5, 0.75, 1.0]
  "down":  "$1:0:-0.5",     // -> [1.0, 0.5, 0.0]
  "angles":"$0:2*pi:pi/2",  // -> [0.0, 1.5707…, 3.1415…, 4.7123…, 6.2831…]
  "n": 4,
  "upto":  "$1:n"           // -> [1, 2, 3, 4]  (bounds may be expressions)
}

A range must be the whole expression: a sequence cannot take part in scalar arithmetic ("$r + 1" where r is a range is an error), the two-part form requires integer bounds, and the step of the three-part form must be non-zero.

Nesting and scoping

Evaluation recurses into nested objects and arrays. Identifiers resolve lexically: the nearest enclosing object's keys are searched first, then its ancestors. Array elements resolve against their nearest enclosing object. A key shadows a same-named constant.

{
  "base": 10,
  "inner": {
    "x": "$base + 5",   // -> 15  (sees the outer `base`)
    "y": "$x * 2"       // -> 30  (sees the sibling `x`)
  }
}

Disabling evaluation for a subtree

An object opts itself and everything nested inside it out of evaluation by carrying a member set to the literal boolean false under the disable key (default "expressionist"). The whole subtree is then left byte-for-byte untouched — nothing inside is even inspected for the expression tag — which makes it cheap to mark a large, static JSON fragment as a no-op instead of tagging every nested object individually. The flag itself is left in the output, and its enclosing scope is otherwise unaffected:

{
  "a": 1,
  "c": "$a + 10",                 // -> 11, evaluated normally
  "frozen": {
    "expressionist": false,
    "b": "$a + 1",                // left as the literal string "$a + 1"
    "inner": { "d": "$a + 2" }    // untouched too, however deeply nested
  }
}

Only a literal false disables evaluation — true, a missing key, or any non-boolean value leaves the object evaluated as usual. Setting the flag on the root object turns the whole document into a no-op (this does not apply to a root-level JSON array, which has no keys to carry the flag). The key name is configurable, and setting it to "" turns the mechanism off entirely:

ex.setDisableKey("skipEval");   // now "skipEval": false is the opt-out
ex.setDisableKey("");           // opt-out mechanism disabled

API summary

Member	Purpose
`Expressionist(json, EvalMethod = RECURSIVE)`	Construct from a JSON object.
`Expressionist(std::string, EvalMethod = RECURSIVE)`	Construct by parsing a JSON string (a `const char*` literal binds here too).
`Expressionist(EvalMethod = RECURSIVE)`	Construct with an empty object, for the by-argument overloads below.
`void evaluate()`	Evaluate the stored object in place.
`void evaluate(json&) const`	Evaluate the given object in place.
`json produce() const`	Evaluate a copy of the stored object and return it.
`json produce(json) const`	Evaluate a copy of the given object and return it.
`void setEvalMethod(EvalMethod)` / `getEvalMethod()`	Select / query the strategy.
`void setTag(const std::string&)` / `tag()`	Set / query the expression tag.
`void setDisableKey(const std::string&)` / `disableKey()`	Set / query the opt-out key (`""` turns it off).
`const json& object() const`	Access the (possibly evaluated) object.
`addConstant(name, value)`	Register a constant.
`addUnaryFunction(name, fn)`	Register a `double(double)` function.
`addBinaryFunction(name, fn)`	Register a `double(double,double)` function.

All failures throw Expressionist::ExpressionistException, whose what() includes the JSON path and expression text.

Building and testing

cmake -Bbuild -GNinja -DCMAKE_BUILD_TYPE=Release
cmake --build build
ctest --test-dir build --output-on-failure

This also builds example/main.cpp (build/expressionist_example), which prints the PURPOSE.md object evaluated with both strategies.

Documentation

Published from main at https://pbosetti.github.io/Expressionist/. It covers the public API only: Expressionist::Expressionist, Expressionist::EvalMethod, Expressionist::ExpressionistException and the C ABI in expressionist_c.h — not the internal tokenizer/parser/evaluator.

To build it locally:

doxygen Doxyfile   # generates doc/html (gitignored, not versioned)

Benchmark

The test suite includes a benchmark comparing the two strategies on large interdependent objects and asserting that they return identical results. The GRAPH method does a bit of graph bookkeeping up front, while RECURSIVE resolves lazily; for these workloads they are close, with RECURSIVE slightly ahead.

Indicative figures (Release build, AppleClang, Apple Silicon):

Workload	GRAPH	RECURSIVE
Dependency chain, 1000 variables	~1.5 ms	~1.1 ms
Wide fan-in, 500 leaves → 1 sum	~0.6 ms	~0.4 ms

Run it yourself:

./build/test/expressionist_tests --test-case="*benchmark*" --success

License

Licensed under the Apache License, Version 2.0.
